Course Description

COMING SOON in January 2024!

This course will develop your skills as a technician in a cleanroom setting. It includes many hands-on trainings in the cleanroom itself to prepare you for a technician job in the wafer manufacturing cleanroom environment.

Individual enrollments: self-enroll on this page
Group enrollments: please contact us at help@professional.ucsb.edu


Course Outline

Once enrolled, please complete before class begins:


DAY CLASSROOM (1 hour per day) CLEANROOM
(3 hours per day)

1

Lab Safety Overview
Industry Introduction
Cleanroom & Gowning & PPE
Semiconductor Basics part 1: Substrates and Photolithography
Outside Tour - facilities
Gowning practice



Safety Review

MakeArt Wafer

2

Pressure sensor explain and process flow

Make Pressure Sensor Pt. 1



Semiconductor Basics part 2: Deposition/Etching/Metrology

Make Pressure Sensor Pt. 2

3

Wafer Handling

Make Pressure Sensor Pt. 3



Metrology Overview

Make Pressure Sensor Pt. 4

4

Statistical Process Control / Quality Systems / Automated Travelers

Make Pressure Sensor Pt. 5



ESD

Metrology Training

5

Recap basic process steps: Litho/Dep/Etch

Demonstrate basic skills



Summary

SEM Intro

Lecture Hours: 13; Cleanroom hours: 27

Learner Outcomes

Upon successful completion of this course, students will have:
  • Knowledge of industry and jobs with technologies requiring cleanroom work environment
  • Knowledge of basic cleanroom processes:  Photolithography, Deposition, Etch and Metrology
And will be able to:
  • Work in cleanroom:  gowning; safety protocols; wafer handling
  • Complete processing steps including photolithography, deposition and etch
  • Do basic metrology
  • Complete wafer traveler and SPC data
Loading...
Classes are offered according to the schedule on the respective Certificate or Program Page. Please click on the Request Information below to be promptly notified when enrollment opens.
